HEP Lab Equipment Database

To add new items, see the instructions here.

Detectors (3 Items)

	Name	Sub-category	Location	Contact	Experiment	Specifications
	MINOS Scintillator Plane	Scintillator	Off-site	jthomas	MINOS	Plastic scintillator detector plane wrapped in tyvek with light coupling; 1m x 1m x 5cm; 17kg
	SuperNEMO Demonstrator Scintillator Long Bar	Scintillator	Off-site	saakyan	SuperNEMO	Plastic scintillator bar wrapped in reflector; 200cm x 10cm x 10cm; 20kg
	SuperNEMO Demonstrator Scintillator Paddle	Scintillator	Off-site	saakyan	SuperNEMO	Plastic scintillator wrapped in reflector in wood box; 211cm x 17cm x 24cm; 17kg

NIM Modules and Crates (24 Items)

	Name	Sub-category	Location	Contact	Experiment	Specifications
	Philips Fast Amplifier	Amplifier	Gordon Street cupboards	saakyan	High Energy Physics
	Philips Fast Amplifier 779	Amplifier	Gordon Street cupboards	saakyan	High Energy Physics
	Concidence Unit	Concidence Unit	Gordon Street cupboards	saakyan	High Energy Physics	3 channel coincidence unit
	LeCroy ECL-NIM Converter	Converter	Gordon Street cupboards	saakyan	High Energy Physics
	NIM-TTL Converter	Converter	Gordon Street cupboards	saakyan	High Energy Physics
	PI Bonn TTL-ECL Converter	Converter	Gordon Street cupboards	saakyan	High Energy Physics
	CERN Nanosecond Delay Unit	Delay	Gordon Street cupboards	saakyan	High Energy Physics	0-32ns delay
	J & P Engineering NM 640 Delay Unit	Delay	Gordon Street cupboards	saakyan	High Energy Physics	Variable delay unit 0-16ns
	Variable Nanosecond Delay Unit	Delay	Gordon Street cupboards	saakyan	High Energy Physics	Variable delay unit 0-64ns
	LRS 620BL Discriminator	Discriminator	Gordon Street cupboards	saakyan	High Energy Physics
	LRS Logic Fan-In Fan-Out	Fan-Out	Gordon Street cupboards	saakyan	High Energy Physics
	Linear Fan-Out	Fan-Out	Gordon Street cupboards	saakyan	High Energy Physics
	LeCroy Logic Fan-in Fan-out	Fanout	Gordon Street cupboards	saakyan	High Energy Physics
	Ortec Fast Filter Amplifier	Fast Filter Amplifier	Gordon Street cupboards	saakyan	High Energy Physics
	Ortec Timing Filter Amplifier	Filter	Gordon Street cupboards	saakyan	High Energy Physics
	Caen N126 General Purpose HV Power Supply	HV Power Supply	Gordon Street cupboards	saakyan	High Energy Physics
	CERN Flip-flop	Logic Unit	Gordon Street cupboards	saakyan	High Energy Physics
	EG&G-ESN CO4010 Quad 4-fold Logic Unit	Logic Unit	Gordon Street cupboards	saakyan	High Energy Physics
	LeCroy Dual Gate Generator	Pulse Generator	Gordon Street cupboards	saakyan	High Energy Physics
	Ortec NIM 480 Pulser	Pulser	Gordon Street cupboards	saakyan	High Energy Physics
	50 Ohm Resistive Splitter	Splitter	Gordon Street cupboards	saakyan	High Energy Physics
	LRS 370 8-Channel Strobed Coincidence	Strobed Coincidence	Gordon Street cupboards	saakyan	High Energy Physics
	Ortec NIM TAC	TDC	Gordon Street cupboards	saakyan	High Energy Physics	Time amplitude converter
	CAEN Dual Timer	Timer	Gordon Street cupboards	saakyan	High Energy Physics

Power Supplies (2 Items)

	Name	Sub-category	Location	Contact	Experiment	Specifications
	Caen Desktop HV Power Supply	HV Power Supply	D106	jolly	PBT	4 Ch Reversible 8 kV/3 mA (8 W) Desktop HV Power Supply; 239 x 84 x 184 mm; 5.2kg
	Caen NIM/Desktop HV Power Supply	HV Power Supply	C23	jolly	PBT	4 Ch Reversible 8 kV/3 mA (8 W) NIM/Desktop HV Power Supply; 221 x 68 x 246 mm; 2.6kg; NIM rack or standalone

Storage and Experimental Enclosures (2 Items)

	Name	Sub-category	Location	Contact	Experiment	Specifications
	PBT Zarges 105L portable experimental enclosure	Experimental enclosure	D27 Physics	jolly	PBT	800mm x 500mm x 385mm external; ~20kg; aluminium with wheels
	PBT Zarges 60L portable experimental enclosure	Experimental enclosure	D27 Physics	jolly	PBT	600mm x 400mm x 385mm external; ~15kg; aluminium with wheels
