FastShower::SmearSoftPhotonBase class Reference

00012                                                               :
00013     IFnOfParticleParameters(), DebugBase(s){
00014
00015     // get histograms' file-names and energies
00016     cout<<"SmearSoftPhotonBase: getting histograms ..."<<endl;
00017     m_histograms = c->histograms();
00018
00019     // loop through files, and setup 1d-dist-randomiser
00020     cout<<"SmearSoftPhotonBase: setting up distributions ..."<<endl;
00021     MCItr_Type1 itr = m_histograms.begin();
00022     MCItr_Type1 end = m_histograms.end();
00023     m_energyDists[0.0] = 0;  // null pointers for end-points
00024     for (;itr!=end; ++itr){
00025       cout<<"SmearSoftPhotonBase:  hist = \""
00026           <<(*itr).second<<"\",  energy = "<<(*itr).first<<"GeV"<<endl;
00027       // pass histogram-file-name to 1d-dist-randomiser
00028       DistRandomiser1D* randomiser = new DistRandomiser1D((*itr).second);
00029       // set the corresponding energy (energy point)
00030       m_energyDists[(*itr).first] = randomiser;
00031     }
00032     m_energyDists[FLT_MAX] = 0;  // null pointers for end-points
00033     cout<<"SmearSoftPhotonBase: distributions done"<<endl;
00034   }

00085                                            {
00086     m_histograms.clear();
00087     std::map<double,DistRandomiser1D*>::iterator itr2 = m_energyDists.begin();
00088     std::map<double,DistRandomiser1D*>::iterator end2 = m_energyDists.end();
00089     for(; itr2!= end2; ++itr2){
00090       delete (*itr2).second;
00091     }
00092     m_energyDists.clear();
00093   }

00036                                                                      {
00037     double energy = pp.rawEnergy();
00038
00039     energy = max((float)energy,FLT_EPSILON);
00040
00041     MCItr_Type2 floor = m_energyDists.begin();
00042     MCItr_Type2 roof  = m_energyDists.end();
00043     /*
00044      * usual case: energy differs from key values in the map => lower==upper
00045      * rare case: energy overlaps with a key entry in the map => lower==upper-1
00046      * energies below/above the floor/roof  =>  valid iterators
00047      * energies overlapping with an energyPoint (i.e. a key) are special!
00048      */
00049
00050     // the following logic works only if the map has at least 3 entries,
00051     // i.e. at least 1 valid entry
00052     std::pair<MCItr_Type2,MCItr_Type2> luItrs = m_energyDists.equal_range(energy);
00053     MCItr_Type2 lowerBound = luItrs.first;
00054     MCItr_Type2 upperBound = luItrs.second;
00055
00056     // force the lower/upperBound iterators to point at 2 consecutive entries
00057     if (lowerBound==upperBound) {--lowerBound;}  // takes care of the usual case
00058     // find the closest boundary
00059     MCItr_Type2 mapEntryPoint = ((energy - (*lowerBound).first)<
00060                          ((*upperBound).first - energy))?
00061       lowerBound : upperBound;
00062
00063     // move up to the 1st valid point if energy is between 0 and the 1st valid point
00064     if (mapEntryPoint == floor) {++mapEntryPoint;}
00065
00066     // check for strange condition that energy is closer to FLT_MAX
00067     // than to the last valid point
00068     MCItr_Type2 ceiling = --roof;
00069     assert(mapEntryPoint != ceiling);
00070
00071     DistRandomiser1D* randomiser = (*mapEntryPoint).second;
00072     double energyPoint = (*mapEntryPoint).first;
00073     double eFrac = randomiser->sample();
00074     nudge(energyPoint,energy,eFrac);
00075     return eFrac;
00076   }

00080                                                                        {
00081     // interpolation
00082     eFrac += (mean(energy) - mean(energyPoint));
00083   }


Public Types
typedef std::map< double, std::string >::const_iterator	MCItr_Type1
typedef std::map< double, DistRandomiser1D * >::const_iterator	MCItr_Type2
Public Methods
	SmearSoftPhotonBase (const ISingleShowererSelectorConfig *, const std::string &)
virtual	~SmearSoftPhotonBase ()
virtual double	value (const ParticleParameters &) const
void	nudge (const double, const double, double &) const
virtual double	mean (const double) const=0
virtual IFnOfParticleParameters *	clone () const=0
Private Attributes
std::map< double, std::string >	m_histograms
std::map< double, DistRandomiser1D * >	m_energyDists

FastShower::SmearSoftPhotonBase Class Reference

Public Types

Public Methods

Private Attributes

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
