HEP PBT Equipment Database

To add new items, see the instructions here.

Detectors (1 Items)

	Name	Sub-category	Location	Contact	Experiment	Specifications
	Caen Desktop Digitizer	Digitiser	D27	Prof. Simon Jolly	PBT	4 Ch 2GS/s Digitiser; 1Vpp input; 154 x 50 x 164 mm; 700g

Electronics and FPGAs (2 Items)

	Name	Sub-category	Location	Contact	Experiment	Specifications
	Kria KR260 Starter Kit	FPGA	D27	Prof. Simon Jolly	PBT	Kria KR260 Robotics FPGA SoM Starter Kit; 120 x 140 x 36 mm; ~500g
	Kria KV260 Starter Kit	FPGA	D27	Prof. Simon Jolly	PBT	Kria KV260 Vision AI FPGA SoM Starter Kit; 120 x 140 x 36 mm; ~500g

Power Supplies (2 Items)

	Name	Sub-category	Location	Contact	Experiment	Specifications
	Caen Desktop HV Power Supply	HV Power Supply	D27	Prof. Simon Jolly	PBT	4 Ch Reversible 8 kV/3 mA (8 W) Desktop HV Power Supply; 239 x 84 x 184 mm; 5.2kg
	Caen NIM/Desktop HV Power Supply	HV Power Supply	D27	Prof. Simon Jolly	PBT	4 Ch Reversible 8 kV/3 mA (8 W) NIM/Desktop HV Power Supply; 221 x 68 x 246 mm; 2.6kg; NIM rack or standalone

Oscilloscopes and Network Analysers (1 Items)

	Name	Sub-category	Location	Contact	Experiment	Specifications
	LeCroy HDO6104 1GHz Oscilloscope	High Definition Digital Oscilloscope	D27	Prof. Simon Jolly	PBT	1GHz 4ch 12-bit Oscilloscope; 2.5GS/s with 50Mpts/ch memory; 292 x 400 x 131 mm; 6kg

Storage and Experimental Enclosures (7 Items)

	Name	Sub-category	Location	Contact	Experiment	Specifications
	PBT Peli 1510 portable experimental enclosure with Thorlabs baseplate	Experimental enclosure	Gordon Street Cupboards	Prof. Simon Jolly	PBT	559 x 351 x 229mm external; ~9kg; HPX polymer with wheels
	PBT Peli 1560 portable experimental enclosure	Experimental enclosure	D27	Prof. Simon Jolly	PBT	560 x 455 x 265mm external; ~9kg; HPX polymer with wheels
	PBT Peli 1660 portable experimental enclosure	Experimental enclosure	Cage	Prof. Simon Jolly	PBT	802 x 584 x 495mm external; ~20kg; HPX polymer with wheels
	PBT Peli Air 1637 portable experimental enclosure	Experimental enclosure	Gordon Street Cupboards	Prof. Simon Jolly	PBT	676mm x 525mm x 378mm external; ~9kg; HPX polymer with wheels
	PBT Zarges 105L portable experimental enclosure	Experimental enclosure	Cage	Prof. Simon Jolly	PBT	800mm x 500mm x 385mm external; ~20kg; aluminium with wheels
	PBT Zarges 60L portable experimental enclosure	Experimental enclosure	Gordon Street Cupboards	Prof. Simon Jolly	PBT	600mm x 400mm x 385mm external; ~15kg; aluminium with wheels
	PBT Peli 1510 flight case	Flight case	Gordon Street Cupboards	Prof. Simon Jolly	PBT	559 x 351 x 229mm external; ~5kg; HPX polymer with wheels
